Name: Mini End Post with Swivel Fittings
Brand: Richelieu Hardware
SKU: 706SP057316170
Price: 542.56 USD
Availability: InStock

Roll over image to zoom in Click on image to zoom

DESCRIPTION

End Post

This system is used as glass railings mini-posts.
Suitable for several applications such as the perimeter of a terrace, the railing of a balcony as well as the wind screen around a swimming pool.

This post attaches directly to the floor and has two swivel arm connections.
It supports glass panels constituting the corner walls of the balustrades.

Includes trim to cover the base of the post after installation.

ADVANTAGES AND BENEFITS

The posts are installed directly on the ground, which ensures a clean look and a clear and unobstructed view.
Swivel arm fittings provide extreme accuracy in the angle alignment of glass panels.

TECHNICAL SPECIFICATIONS

Product № 706SP057316170

Type of Mounting Floor Mount

Safety Glass Thickness 10 to 12 mm

Finish Stainless Steel

Thickness 25 mm

Mounting Side Reversible

Height 488 mm

Width 50 mm

Material Stainless Steel: 316

Glass Drilling Not Required

Recommended Location Usage Interior, Exterior

Load Capacity for Two Brackets Max. 45 kg

Milling C/C 200 mm

Milling Diameter 11 mm

APPLICATION

Glass drilling is required for use.
No handrails or overlay molding is required for the use of these mini-posts.

INCLUDED PRODUCT(S)

1 support, 1 trim, and mounting hardware

IMPORTANT INFORMATION

The distance between the top and bottom fittings is 200 mm (7-7/8") center to center.

For safety reasons, it is recommended to use tempered glass.
The glass must be shaped according to the cutting plan provided in the box.

Be sure to attach the product to a suitable material.
Be sure to order the hardware before starting work.
Never exceed the maximum load and dimensions recommended by the manufacturer.

The image is provided for visual reference purposes only. The product may differ from the illustration.
The manufacturer reserves the right to modify any product or information without notice. Always follow the instructions provided in the package.
